Power Source

Batteries :   8 x 6V, 370 A-h
Electrical System:  48 Volts DC

Performance

Drive Speed - Platform Lowered:  3.2 mph / 5.15 km/h
Gradeability - 2WD:    30 %
Platform Capacity:  500 lb / 226.80 kg
Platform Capacity - Unrestricted: 500 lb / 226.80 kg
Swing: 360 Degrees
Swing Type: Non-Continuous
Turning Radius - Outside 10 ft 4 in. / 3.15 m
Jib - Range of Articulation: 141 Degrees

Reach Specifications:

Horizontal Jib Rotation:   0 Degrees
Horizontal Outreach:  23 ft 9 in. / 7.24 m
Platform Height:  45 ft / 13.72 m
Up and Over Height:   25 ft 3 in. / 7.7 m

General:
Capacity - Hydraulic Reservoir:   4 gal. / 15.14 L            Machine Weight:  14400 lb / 6531.73 kgMaximum Ground Bearing Pressure: 110 psi / 7.70 Kg/cm2

Platform Height:  45 ft / 13.72 m

Machine Width: 5 ft 9 in. / 1.75 m

Platform Capacity - Unrestricted: 500 lb / 226.80 kg

• Machine is ready for inspection and/or shipping
• Technical data without obligation – subject to prior sale
• Specifications and location are subject to change without notice
