Used Wysong 250 Ton Press Brake #5006
Description
:USA 2001
:Press Brake
:Wysong
:F68-250-168
:575V-44AMP/60Hz/3Phz
:5006
:Used
:Cambridge, Ontario, Canada
:
Request Quote
AVAILABLE
| Specifications | Metric show Imperial | Imperial show Metric |
| Pressing Force | 226.8 tons | 250 tons |
| Distance Between Tie Bars (D x W) | 3784.6 mm | 149 inch |
| Stroke | 254 mm | 10 inch |
| General | ||
| Motor Power | 15 kW | 20 hp |
| Machine Weight (approx): | 15.9 kg | 35,000 lbs |
| Size (L x W x H): | 54.9 x 23.8 x 37.2 m | 180″ L-R x 78″ F-B x 122″ Tall ft |
ADDITIONAL SPECIFICATIONS
Capacity:Â 250 Tons
Overall Bed Length: 168″
Distance Between Housings: 149″
Stroke: 10″
Throat Depth: 10″
Ram Adjustment: 9″
Maximum Die Space: 19″
Equipped With:
Die Rail
Manual Back Stop
Free Standing Palm Button Pedestal
Motor: 20 HP 575V-44AMP/60Hz/3Phz
CONTROL
Equipped With:
Die Rail
Manual Back Stop
Free Standing Palm Button Pedestal
AVAILABILITY AND TERMS
- Machine is ready for inspection and/or shipping
- Technical data without obligation – subject to prior sale
- Specifications and location are subject to change without notice
What's Included
Used Press Brake Die Casting Machine
Product Overview
Used Press Brake Die Casting Machine
Features
- Core Circuits
- Hyd Ejection
- PLC Control
- Remote Diag
- Touch Screen
